Description
An ultra-quiet inline duct fan designed for residential and light commercial ventilation where noise reduction is essential.
The TD-SILENT 160 features a patented floating motor system and sound-absorbent insulation for whisper-quiet performance, making it ideal for installations in bedrooms, offices, and other occupied spaces. Its low-profile housing allows easy integration in confined areas like ceiling voids or narrow ducts.
- Airflow up to 180 m³/h at maximum speed
- 230V–50Hz single-phase, 2-speed & 3-speed motor
- Floating motor mounted on silentelastic-blocks to minimise vibration
- Sound pressure level: 22–24 dB(A) at 3 metres
- Thermal overload protection for motor safety
- Motor insulation class: Class B
- Ingress protection: IP44
- Operating temperature range: -20°C to +40°C
- Compatible duct size: Ø100 mm
- Fully removable fan body for easy cleaning and maintenance
- 360º rotatable terminal box for flexible cable connection
- Rubber gaskets on inlet/outlet to reduce vibration
- Supplied with mounting brackets for wall or ceiling installation
- Compatible with speed controllers: COM-2, REGUL-2, RMB-1.5, REB-1
Installation must be carried out by a qualified professional in compliance with local regulations.
