Description
A high-performance inline duct fan designed for commercial, industrial, and high-humidity environments where strong airflow is essential.
With a conically shaped impeller and diffuser for enhanced air pressure and low noise, the Boost 200 is ideal for systems requiring high capacity and efficiency. Its durable polymer casing and IPX4-rated motor ensure long-term reliability in demanding applications.
- Airflow up to 1140 m³/h at maximum speed
- 230V–50Hz single-phase, three-speed asynchronous motor
- Thermal overload protection for enhanced motor safety
- Conical polymer impeller with specially profiled blades for increased pressure
- Sound pressure level: 37–42 dB(A) at 3 metres
- Rated for continuous operation in temperatures from -25°C to +55°C
- Ingress protection: IPX4
- Motor insulation class: IP20
- Compatible duct size: Ø200 mm
- Easy installation with mounting brackets and optional external speed controller (P3-5.0)
- Designed for floor, wall, or ceiling mounting in any orientation
- Suitable for series or parallel configuration for pressure or airflow optimisation
Please ensure installation is performed by a qualified technician in accordance with local electrical and ventilation standards.
